12V PCB Mount T-Type SPDT Relay

₹70.00 ₹59.32
Availability: In stock
SKU
PRO1203

T Shape Relay with switching capacity 30 Amps in small size for various use.
Simple magnetic circuit to meet mass production for low range .
Dust cover and sealed cover available to meet various requirements.

Applications :

Inverters, Heating, Controllers, Domestic Appliances,

Features :

Coil Voltage - 12VDC Ampere - 20/30A 1 Form C (CO) with 6 Pins
Operating Temperature - (-25C ~ + 55C)
Weight - Approx 27.2 gm
Product Dimensions L * W * H (MM) - 32.2 * 27.5 * 20.2 mm ,
Pins - Form 1C (CO) ,
Coil Voltage - 12VDC
Ampere Rating - 1CO : (NC : 10A @ 240VAC / NO : 20A @ 240VAC)
Coil Power Consumption - 0.93W
Coil Resistance ( 10%) - 155
Colour - Black
Terminal Type - PCB.
