20 x 4 LCD with Green Backlight

This is a basic 20 character by 4 line display. Interface code is freely available. You will need ~11 general I/O pins to interface to this LCD screen. Includes LED backlight.

If you want to add some visual output to your Arduino projects, you’ll need a display. If you need moderate data on display, the LCD2004 Parallel LCD Display is a quite good solution for the Arduino projects.

It works of 5V and has a Green Backlight which can be switched on and off as desired. The contrast of the screen can also be controlled by varying the voltage at the contrast control pin.

Specification :

• Wide viewing angle and high contrast.
• Industry-standard JHD629-204A equivalent LCD controller built-in.
• +5V DC supply with 33 Ohm resistor LED backlight.
• Supported 4 or 8-bit parallel interface.
• Display 4-line X 20-character.
• Operate with 5V DC.=
• Interface with 16 pins male header Connector.
• 20 characters wide, 4 rows
• Black text on the yellow background
• The module can easily interface with an MCU
• The module is a low-power consumption character LCD Module with a built-in controller
• Single LED backlight included can be dimmed easily with a resistor or PWM.
• Can be fully controlled with only 6 digital lines! (Any analog/digital pins can be used)
