It is a simple DC motor featuring metal gearbox for driving the shaft of the motor. The RS50 Geared Motors are known for their massive torque-speed characteristic.The RS50 Geared Motors comes with side shaft also known as an off-centered shaft and two M4 mounting holes.
The motor will run smoothly between the voltage range 6 to 15 V DC and give you 60 RPM at 12V supply.
The RS50 Geared Motor gives very good torque at an affordable price hence they are widely applicable in Pan/Tilt camera, auto shutter, welding machines, water meter IC card, grill, oven, cleaning machine garbage disposers, household appliances, slot machines, money detector, automatic actuator, coffee machine, towel disposal, lighting coin refund devices, the peristaltic pump and so on.
Also, they are best suitable with highly developing capable robots or robotic platform, various automation purposes.
Model : RS-50
Operating Voltage Range : 6V to 15V DC | Load current: 3A max
Recommended Voltage (DC) 12V
Rated RPM (at 12V) 60
Rated Torque (Kg-cm) 13
No- Load Current (A) 0.2
Full Load Current (A) 4.8
Full (Stall) Load Torque (Kg-cm) 40
Base Motor Dimensions (mm) 37.7 x 65.8 (Diameter x Length)
Gearbox Dimensions (mm) 51.2 x 34 (Diameter x Length)
Motor Shaft Length (mm) 21.18
Shaft Diameter (mm) 7.15
Motor Shaft Type D
Weight (gm) 360
Note : Please note that this motor will have a +/- 10% error in the RPM.
