Active Antenna for GPS Modules

Active Antenna for GPS Modules

Active Antenna for GPS Modules

₹234.82 ₹199.00
Warranty: None
Availability: In stock
SKU
PRO252
The External GPS antenna has a center frequency of 1575.42 ± 3MHz. The output VSWR is <2.0. The band width offered is 20MHz with an impedance of 50 ohms. The antenna has got a Magnetic base for the ease in mounting. Also the material is weather proof.

GPS External Antenna Specification:

Electrical Data:

Center Frequency: 1575.42 ± 3MHz
Output VSWR: <2.0
Band width: 20MHz
Impedance: 50 Ohms
Polarization: RHCP
LNA gain (without cable): 28 ±2dB type (3.3 to 5V)
Noise figure: <2dB (maximum) (at 3.3V)
Voltage: 3.3 to 5V DC
DC current: 50mA (maximum)
Working power: 300mW (minimum) and 1.5W (maximum)

Mechanical Data:

Weight: 73g
Size: 50 x 37 x 18mm
Cable: RG174
Connector: SMA male
Mounting: magnetic base
Housing: black matte
Working temperature: -40 to +85°C
Humidity: 95 to 100% RH
Weatherproof: IP67
