APM Power Module BEC Pixhawk Ardupilot Quadcopter XT60 Connector

The APM Power Module is a simple way of providing your APM 2.5/6 with clean power from a LiPo battery as well as current consumption and battery voltage measurements, all through a 6-pos cable. The on-board switching regulator outputs 5.3V and a maximum of 2.25A from up to a 6S LiPo battery. The Power Module comes completely assembled with XT60 black connectors and wrapped in shrink tubing for protection.

Note: The Power Module is only designed to power APM, a RC receiver and APM accessories (GPS, 3DR radio). It is not designed to power servos. Use your aircraft’s own ESC/BEC for that.

Specifications

• Max input voltage: 28V
• Max current sensing: 90A
• Voltage and current measurement configured for 5V ADC
• Switching regulator outputs 5.3V and 3A max
• 6-pos DF13 cable plugs directly to APM 2.5’s ‘PM’ connector
• Support 6S battery
