Attiny85 8 Pin AVR DIP Microcontroller IC

Attiny85 8 Pin AVR DIP Microcontroller IC

Attiny85 8 Pin AVR DIP Microcontroller IC

₹140.42 ₹119.00
Warranty: None
Availability: In stock
SKU
PRO689

Atmel’s small 8 pin ATtiny85 8-Bit Processor. Comes with 8K of program space, 6 I/O lines, and 4-channel 10 bit ADC. Runs up to 20MHz with external crystal. IC can be programmed in circuit.

ATtiny85 is a small 8-pin microcontroller from Atmel and is based on Atmel's 8-bit RISC architecture. ATtiny85 is a high-performance, low-power microcontroller which combines 8KB ISP flash memory, 512B EEPROM, 512-Byte SRAM, 6 general purpose I/O lines, 32 general purpose working registers, one 8-bit timer/counter with compare modes, one 8-bit high speed timer/counter, USI, internal and external Interrupts, 4-channel 10-bit Analog to Digital converter, programmable watchdog timer with internal oscillator, three software selectable power saving modes, and debug WIRE for on-chip debugging. The device achieves a throughput of 20 MIPS at 20 MHz and operates between 2.7-5.5 volts.

By executing powerful instructions in a single clock cycle, the device achieves throughputs approaching 1 MIPS per MHz, balancing power consumption and processing speed.



Features :-

  • Flash (Kbytes): 8 Kbytes
  • Pin Count: 8
  • Max. Operating Freq. (MHz): 20 MHz
  • CPU: 8-bit AVR
  • Number of Touch Channels: 3
  • Hardware QTouch Acquisition: No
  • Max I/O Pins: 6
  • Ext Interrupts: 6
  • USB Interface:No
