Digital Proximity And Ambient Light Sensor APDS-9930

₹249.00 ₹211.02
Availability: In stock
SKU
PRO2067

Description:

This is APDS-9930 Digital Proximity And Ambient Light Sensor for Arduino. The APDS-9930 provides digital ambient light sensing (ALS), IR LED and a complete proximity detection system in a single 8 pin package. The proximity function offers plug and play and detection to 100 mm (without front glass) thus eliminating the need for factory calibration of the end equipment or sub-assembly.

The proximity detection feature operates well from bright sunlight to dark rooms. The wide dynamic range also allows for operation in short distance detection behind dark glass such as a cell phone.

In addition, an internal state machine provides the ability to put the device into a low power mode in between ALS and proximity measurements providing very low average power consumption. The ALS provides a photopic response to light intensity in very low light conditions or behind a dark faceplate.

Specifications:

  1. Working voltage:2.8-3.8V
  2. ALS, IR LED and Proximity Detector in an Optical Module;
  3. Ambient Light Sensing (ALS);
  4. Approximates Human Eye Response;
  5. Programmable Interrupt Function with Upper and Lower Threshold;
  6. Up to 16-Bit Resolution;
  7. High Sensitivity Operates Behind Darkened Glass;
  8. Low Lux Performance at 0.01 lux.

Applications:

  • Adjustable light mobile phone backlight
  • Notebook / display security
  • automatically enabled hands-free mode
  • Automatic menu pop up
  • Digital camera eye sensor.

Package Includes:

1 x Digital Proximity And Ambient Light Sensor APDS-9930
