INA219 Power Monitoring Sensor DC Voltage and Current Module

INA219 Power Monitoring Sensor DC Voltage and Current Module

INA219 Power Monitoring Sensor DC Voltage and Current Module

₹350.00
Warranty: None
Availability: In stock
SKU
PRO987

This breakout board will solve all your power-monitoring problems. Instead of struggling with two multimeters, you can just use the handy INA219B chip on this breakout to both measure both the high side voltage and DC current draw over I2C with 1% precision.

A precision amplifier measures the voltage across the 0.1 ohm, 1% sense resistor. Since the amplifier maximum input difference is ±320mV this means it can measure up to ±3.2 Amps. With the internal 12 bit ADC, the resolution at ±3.2A range is 0.8mA. With the internal gain set at the minimum of div8, the max current is ±400mA and the resolution is 0.1mA. Advanced hackers can remove the 0.1 ohm current sense resistor and replace it with their own to change the range (say a 0.01 ohm to measure up 32 Amps with a resolution of 8mA)


Specifications and Features:

0.1 ohm 1% 2W current sense resistor
Up to +26V target voltage
Up to ±3.2A current measurement, with ±0.8mA resolution
0.9″ x 0.8″ PCB
PCB (no header or terminal block): 1.9g
Senses Bus Voltages from 0 to 26 V
2C- or SMBus-compatible interface. The
Reports Current, Voltage, and Power
16 Programmable Addresses
Filtering Options
Calibration Registers
SOT23-8 and SOIC-8 Packages
