Infrared Thermopile Sensor

₹299.00 ₹253.39
Availability: In stock
SKU
PRO2060

Description:

Infrared Thermopile Sensor can measure the temperature without contact by detecting the infrared energy of an object. And the higher the temperature, the more infrared energy is produced.

Thermopile sensing elements consist of small thermocouples on silicon chips that absorb energy and produce output signals.  Infrared Thermopile Sensor can be widely used in non-contact temperature measurement. This product consists of infrared filters, thermistors, and other components, it has high reliability and high sensitivity.

Specifications:

  1. Fast response 5μm Long-wave pass filter
  2. Detection angle: 90°
  3. Thermopile resistance: 95 to 140 KΩ
  4. Noise voltage: 45 nV/Hz1/2
  5. NEP: 0.27 nW/Hz1/2
  6. Voltage Response: 20.11 Vmm2/w
  7. Responsivity: 124

Applications:

  1. Non-contact Temperature Measurement
  2. Ear Thermometer, Forehead Thermometer
  3. Industrial Continuous Temperature Control

Package Includes:

1 x Infrared Thermopile Sensor
