IRF520 Mosfet Driver Module for Arduino/Raspberry pi

₹119.00 ₹100.85
Availability: In stock
SKU
PRO1289
IFR520 MOSFET transistor Module is designed to switch heavy DC loads from a single digital pin of your microcontroller. Its main purpose is to provide a low cost way to drive a DC motor for robotics applications, but the module can be used to control most high current DC loads. Screw terminals are provided to interface to your load and external power source. An LED indicator provides a visual indication of when your load is being switched.

Features:
  • Adopt original IRF520 power MOS tube, can adjust PWM output
  • Can drive loads up to 24V , such as LED strips, DC motors, micro pumps, solenoid valves
  • LED PWM can be used to realize stepless dimming of LED and stepless speed regulation of motor
  • Note: Heat sinks need to be installed for loads above 1A
Specifications:
  • Voltage: 3.3V and 5V
  • Port: Digital level
  • Output load voltage: 0-24V
  • Platform: MCU, ARM , Raspberry Pi
  • Size: 33*24mm
  • Weight: 10 g
