Max30100 Pulse Oximeter Heart-Rate Sensor Module

Max30100 Pulse Oximeter Heart-Rate Sensor Module

Max30100 Pulse Oximeter Heart-Rate Sensor Module

₹253.70 ₹215.00
Warranty: None
Availability: In stock
SKU
PRO1280

MAX30100 is an integrated pulse oximetry and heart-rate monitor sensor solution. It integrates two LEDs (IR and Red), a photodetector (Red), optimised optics, and low-noise analog signal processing to detect pulse oximetry and heart-rate signals. It is fully configurable through software registers and the digital output data is stored in a 16-deep FIFO within the device.It has an I2C digital interface to communicate with a host microcontroller.

The pulse oximetry subsystem in MAX30100 consists of ambient light cancellation (ALC), 16-bit sigma delta ADC, and proprietary discrete time filter. It has an ultra-low-power operation which makes it ideal for battery operated systems.MAX30100 operates on a supply in the range of 1.8 to 3.3V.It can be used in wearable devices, fitness assistant devices, medical monitoring devices, etc.The MAX30100 operates from 1.8V and 3.3V power supplies and can be powered down through software with negligible standby current, permitting the power supply to remain connected at all times.

NOTE: MAX30100

This sensor works on 3.3V Devices directly. You can connect it to 3.3V devices like ESP8266, ESP32, etc directly. To use it with the Arduino UNO, Mega, Nano, etc use a level shifter in between. Else I2C connection will not work.

We have tested this sensor with this library - MAX30100 by Connor Huffine and it works perfectly.

Specifications and Features:

  1. Optical sensor: IR and red LED combined with a photodetector
  2. Measures absorbance of pulsing blood
  3. I2C interface plus INT pin
  4. 3.3V power supply complete pulse oximeter and heart rate sensor solution, simplifies design, integrated LEDs, photo sensor, and
  5. high-performance analog front
  6. Ultra low power operation increases battery life for wearable devices
  7. Advanced functionality improves measurement performance, high SNR provides robust motion artifact resilience integrated
  8. ambient, light cancellation high sample rate capability fast data output capability
  9. It is an integrated pulse oximetry and heart rate monitor sensor solution.
