NRF51822 BLE Bluetooth 4.0 Module Nordic for IoT CORE51822

NRF51822 BLE Bluetooth 4.0 Module Nordic for IoT CORE51822

NRF51822 BLE Bluetooth 4.0 Module Nordic for IoT CORE51822

₹765.82 ₹649.00
Availability: Out of stock
SKU
PRO838

This module called the CORE51822 is a wireless module based on nRF51822 - the Multiprotocol Bluetooth® 4.0 low energy/2.4 GHz RF SoC IC designed for ULP (ultra low power) wireless applications. The NRF51822 is a one the most popular BLE ICs available. Its huge popularity ensures, you will find numerous resources, tutorials and sample codes for the module. Nordic also provides a lot of sample codes to demonstrate everything from blinking LEDs to communicating with smartphones through BLE. This makes it easy to start development with the NRF51822 IC and get your product ready faster.

You may use this module with our NRF51822 Development Board which let you do rapid prototyping and quickstart your product development. You will require a compatible programmer to upload codes to the NRF51822 IC. You may use our ARM JLink Programmer to program and debug this module.

CORE51822 Specifications:

  • Onboard BLE chip: nRF51822
  • Communication distance (open outdoor@1M data rate): 30m
  • Frequency range: 2.4GHz
  • Operating voltage: 2.0V ~ 3.6V
  • Operating temperature: -40° ~ 85°
  • Dimension (PCB): 24.5mm x 32.26mm
  • Expansion pinheader: all the I/Os except P0.26 and P0.27
  • Pinheader pitch: 2.00mm
  • Spacing between pinheaders on the left side and the right side: 18.00mm
  • Antenna: onboard antenna

NRF51822 Features:
  • 2.4 GHz multiprotocol RF transceive
  • 128 bit AES HW encryption
  • 128kB flash & 16Kb RAM
  • Programmable Peripheral Interconnect (PPI)
  • Digital interfaces: SPI, I2C, UART
  • 10 bit ADC
  • Programmable output power: -20 to +4 dBm
  • Independent application development and protocol stack
  • Fully compatible with NRF24L series
  • Pinout compatible with NRF51xxx series
  • Global separate power management
  • Operating voltage: 1.8 V ~ 3.6 V

Applications:
  • Wearable devices
  • Bluetooth intelligent application
  • Mobile phone accessories
  • RFID labels
  • Smart home appliances
  • Industry control
  • Data acquisition system

Related Documents

Package includes:
  • 1 x NRF51822 based CORE51822 Module
