Proximity Sensor SN04-N Inductive Obstacle Distance NPN Type

Proximity Sensor SN04-N Inductive Obstacle Distance NPN Type

Proximity Sensor SN04-N Inductive Obstacle Distance NPN Type

₹229.00
Availability: Out of stock
SKU
PRO901

This NPN inductive proximity sensor can detect the presence of metals objects in front of it. The detection distance may vary slightly depending on the shape, size, and type of metal the object is made of. It can detect through thin, non-metallic materials and has an LED indicator that turns on when the device is powered, and increases in brightness when an object is detected. This inductive sensor can detect metallic objects within 5mm and behaves like a switch that connects to a digital input.

This sensor is perfect for use in 3D Printers, CNC Machines, to detect the initial positions and for bed auto levelling. You can also use this module for optical encoders, robotics, DIY Electronics, etc

Features

  • Model:SN04-N
  • Output: NPN Type output
  • 3 wire,NO
  • Size:18*18*36mm
  • Work Voltage:6VDC-36VDC
  • Detection Distance:5mm
  • Output Current:300mA
  • Crust Material:Plastic
  • Working Voltage : DC 10-30V
  • Package Content : 1 x Proximity Sensor Switch,2 x Screws
Product Features
  • Detects metallic objects
  • Standard Detecting Distance: 5mm
  • NPN Normally Open output
  • Requires a 6 to 36VDC Power Supply
