SIM28ML GSM GPRS Module

₹599.00 ₹507.63
Availability: In stock
SKU
PRO1572

SIMCom presents a small, high performance and reliable assisted GPS module-SIM28ML. This is a standalone L1 frequency GPS module in a SMT type and it is designed with MTK high sensitivity navigation engine, which allows you to achieves the industry’s highest levels of sensitivity, accuracy, and Time-to-First-Fix (TTFF) with lowest power consumption.

SIM28ML is a stand-alone or A-GPS receiver. With built-in LNA, SIM28ML can relax antenna requirement and don’t need for external LNA. SIM28ML can track as low as -165dBm signal even without network assistance. The SIM28ML has excellent low power consumption characteristic (acquisition 16mA, tracking 15mA). SIM28ML supports various location and navigation applications, including autonomous GPS, QZSS, SBAS ranging (WAAS, EGNOS, GAGAN, MSAS), RTCM and A-GPS.

Features :
Support EPOTM orbit prediction
Support SBAS ranging (WAAS, EGNOS, GAGAN, MSAS)
Support Jamming removing function
Low-noise amplifier has been integrated

Interfaces :
Serial interfaces : UART
Digital I/O : TIMEMARK (PPS) , GPIO
Protocols : NMEA , PMTK

Eectrical data
Power supply: +2.8V ~4.3V
Backup power: +2.0V ~4.3V
Power consumption
Acquisition: 17mA
Tracking: 16mA
Backup: 8μA
Antenna type
Active and Passive
Antenna power
External


Performance data :
Receiver type :22 tracking / 66 acquisition- channel GPS receiver GPS L1, C/A Code
Max. update rate : 5Hz
Sensitivity1
Tracking: -165 dBm
Reacquisition: -160 dBm
Cold starts: -148 dBm
Time-To-First-Fix2
Cold starts: 32s (typical)
Warm starts: 3s
Hot starts: <1s
EPO Assist: 13s (CTTFF)
Accuracy
Automatic Position3: 2.5m CEP
Speed4: 0.1m/s
Operation temperature: -40℃~+85 ℃
